Suntech ST4290L on TrackeraX
The Suntech ST4290L is a GPS tracker that works with TrackeraX over the suntech protocol on port 6011. From the platform it supports engine stop, engine resume and arm alarm, plus custom commands. The server decodes 15 alarm types from this protocol, such as accident, door and geofence entry.
[ How to connect it to TrackeraX ]
- Insert a SIM card with mobile data and set the APN of your carrier on the device.
- Set the server to the domain of your TrackeraX platform and the port 6011 (suntech protocol).
- Create the device in TrackeraX with its IMEI or identifier and choose the Suntech ST4290L model.
- Wait for the first position and turn the parameters above into sensors and alerts.
The exact commands to set the APN and server depend on the firmware: check the manufacturer's manual or ask our support team.
[ Commands you can send from TrackeraX ]
Available from the web platform and the apps. The custom command sends any text the device firmware accepts.
- Engine stopengineStop
- Engine resumeengineResume
- Arm alarmalarmArm
- Disarm alarmalarmDisarm
- Request positionpositionSingle
- Reboot devicerebootDevice
- Output controloutputControl
- Custom commandcustom
[ Data reported by the suntech protocol ]
Parameters the server decodes from this protocol. In TrackeraX you turn them into sensors, alerts and reports. Each model reports the ones its firmware and wiring allow.
- Battery voltagebattery
- Driver ID (RFID / iButton)driverUniqueId
- Fuelfuel
- G-sensorgSensor
- Engine hourshours
- Ignitionignition
- Digital inputsinput
- Motionmotion
- Odometerodometer
- Digital outputsoutput
- External powerpower
- RPMrpm
- GSM signalrssi
- Satellitessat
- Firmware versionversionFw
Numbered inputs and sensors
- Analog inputs (adc1, adc2…)
- Inputs (in1, in2…)
- IO elements (io1, io2…)
- Outputs (out1, out2…)
- Temperature sensors (temp1, temp2…)
[ Alarms the protocol can report ]
- Accidentaccident
- Doordoor
- Geofence entrygeofenceEnter
- Geofence exitgeofenceExit
- Harsh accelerationhardAcceleration
- Harsh brakinghardBraking
- Jammingjamming
- Low batterylowBattery
- Movementmovement
- Overspeedoverspeed
- Parkingparking
- Power cutpowerCut
- Power restoredpowerRestored
- SOSsos
- Vibrationvibration
[ Protocol-specific attributes ]
alertData · alertId · alertModifier · assign · drivingQuality · fuel1 · fuel2 · journey · mode · reason · serial · tag
[ Other Suntech models ]
Suntech ST4290L FAQ
Which port does the Suntech ST4290L use to connect to TrackeraX?
The Suntech ST4290L uses the suntech protocol and connects to port 6011 on your TrackeraX server. Just set your platform domain and that port on the device.
What data does the Suntech ST4290L send to the platform?
TrackeraX reads 20 parameters of the suntech protocol on this device, for example: Battery voltage, Driver ID (RFID / iButton), Fuel, G-sensor, Engine hours. Each one can become a sensor or an alert.
Can I send commands to the Suntech ST4290L from TrackeraX?
Yes. From the map or the device page you can send 7 command types to the Suntech ST4290L, including: Engine stop, Engine resume, Arm alarm, Disarm alarm, Request position.
Which alarms does the Suntech ST4290L report?
TrackeraX recognizes these suntech alarms: Accident, Door, Geofence entry, Geofence exit, Harsh acceleration. Any of them can become an email, push or webhook notification.
How do I add the Suntech ST4290L to my platform?
Insert a data SIM, set the APN, point the device to your platform domain on port 6011 and create it in TrackeraX with its IMEI, choosing the Suntech ST4290L model.
